Overview – HOSE BRACE 3093506 Series
The Cummins HOSE BRACE 3093506 fits Cummins hydraulic positions as the hose brace supporting and locating a hose run; because multiple part numbers interchange, we list the related series so you can match what is on your machine.
Parts Characteristics
A hose brace that supports and locates a hose run, so the hose stays clear of chafe and the fittings stay aligned. It carries the support that the line cannot hold alone, so a true, secured brace keeps the hose from rubbing through.
Applicable Models & Applications
Used at Cummins hydraulic positions specifying this hose brace (series). Match the clamp, the standoff and the mount against your old brace – hose braces differ in how they carry and clamp.
Maintenance & Replacement
Inspect for a loose clamp and a cut pad at every hydraulic service. A brace that has begun to slip lets the hose swing, and the swing is what chafes the cover.
Confirm the brace holds the hose off the structure on fit. A brace canted in its bolts lets the hose touch, and the touch is where it wears through.
Replace rather than retie a damaged one. A brace whose pad has gone cannot hold the hose off the frame, and the hose is what fails.
Keep the correct hose brace for your circuit on the bench. It is cheap next to a hose, and it is exactly the part missing when a line needs supporting today.
Price Reference (USD)
Budget roughly USD 8 to USD 55 for a HOSE BRACE 3093506; volume orders and stock status can move this range either way.
Value & Service
We supply brand-new Cummins hose braces with the clamp and standoff confirmed against your circuit, so the hose stays clear.
This HOSE BRACE is supplied alongside the following series references: 3349339, 3642800, 4068311, 4068681, 4095498, 4100888, 4381191, 4924690, 5349702F, C5338687, C5344770, C5399008, C5399009, C5447082. Any of these can be quoted on request.
Choose Racer Machinery for the HOSE BRACE 3093506 and other Cummins Hydraulic Parts – genuine-spec replacements sourced and inspected before they leave the warehouse.
